WLAN 2300 Series Outdoor Solution with Indoor Mounted AP 47
Nortel WLAN 2300 Series Outdoor Solution Guide
The following table summarizes the net effective loss for the three connection scenarios outlined above. In
general, for the 2.4 GHz operating frequency band, Scenario 1 will have an additional loss of 3.0 dB, Scenario
2 will have an additional loss of 4.9 dB and Scenario 3 will add a loss of 6.9 dB.
Surge suppressor (lightning arrestor)
The Nortel series gas-discharge surge suppressors (lightning arresters) provide high-level protection for
transmitters and receives at RF-communication sites. In the event of a local strike, the unit’s gas discharge tube
ionizes instantaneously to limit sudden voltage surges across the coaxial line. When connected to a satisfactory
ground, the unit can safely shunt up to 5000 Amps of impulse current away from sensitive station equipment.
Table 11. Loss associated with 10-foot and 25-foot outdoor rated extension
cables Loss associated with 10-
Connects surge
suppressor to
Antenna
Outdoor Cable (LMR-240)
Component 10 ft Cable 25 ft Cable
Frequency
(MHz)
Loss (dB) Loss (linear) Loss (dB) Loss (linear)
2400 - 2500 -1.84 0.345 -3.89 0.591
5150 - 5250 -2.68 0.460 -5.70 0.731
5250 - 5350 -2.79 0.474 -5.81 0.737
5470 - 5725 -2.78 0.473 -5.91 0.743
5725 - 5850 -2.81 0.476 -5.93 0.745
Table 12. Summary of loss for three scenarios
Outdoor Combinations
Configuration Scenario 1 Scenario 2 Scenario 3
Frequency
(MHz)
Loss (dB) Loss (linear) Loss (dB) Loss (linear) Loss (dB) Loss (linear)
2400 - 2500 -3.02 0.501 -4.86 0.673 -6.91 0.796
5150 - 5250 -5.36 0.709 -8.04 0.843 -11.06 0.922
5250 - 5350 -5.38 0.710 -8.17 0.847 -11.18 0.924
5470 - 5725 -5.70 0.731 -8.48 0.858 -11.61 0.931
5725 - 5850 -5.87 0.741 -8.68 0.865 -11.81 0.934
