Appendix 71
Nortel WLAN 2300 Series Outdoor Solution Guide
Table 14: Outdoor External Antenna Selection Guide
Cushcraft
Nortel
Model
Number
WSS
Model
String
WLAN AP-2330A and AP-2330B 2.4 GHz
Antennas
S2403BPXN36RSM DR4000088E6 24993 WLAN Collinear Omni-directional Dipole Antenna that contains
two collocated elements with an average gain of 4.9 dBi and a
3-foot cable with a Reverse SMA connector. For use in
Warehouses, Auditoriums, Shopping Malls, industrial complexes
and more. It can be mounted either on a pole or hung from a
ceiling.
24993-
NEMA
To be used with the outdoor NEMA enclosure only. Output
power is compensated for the addition of the 10-foot plenum
rated cable and the lightning protection circuitry.
24493-
NEMA-10
To be used with the outdoor NEMA enclosure only. Output
power is compensated for the addition of the 10-foot plenum
rated cable, the lightning protection circuitry and the 10-foot
outdoor rated extension cable.
24493-
NEMA-25
To be used with the outdoor NEMA enclosure only. Output
power is compensated for the addition of the 10-foot plenum
rated cable, the lightning protection circuitry and the 25-foot
outdoor rated extension cable.
24993-
OUT
Output power is compensated for the addition of lightning
protection circuitry and the 10-foot plenum rated cable.
24993-
OUT-10
The "10" refers to the addition of the 10-foot outdoor-rated
LMR-240 extension cable. Output power is compensated for the
addition of the 10-foot plenum rated cable, the lightning
protection circuitry and the 10-foot outdoor rated extension
cable.
24993-
OUT-25
The "25" refers to the addition of the 25-foot outdoor-rated
LMR-240 extension cable. Output power is compensated for the
addition of the 10-foot plenum rated cable, the lightning
protection circuitry and the 25-foot outdoor rated extension
cable.
S2409PN36RSM DR4000076E6 24883 WLAN Directional Patch Panel Array Antenna with an average
gain of 8.8 dBi and a 3-foot cable with a Reverse SMA connector.
For use where a shaped pattern is needed to provide enhanced
coverage of deep rooms, warehouse bays, or any elongated
activity zone.
