Appendix 73
Nortel WLAN 2300 Series Outdoor Solution Guide
Cushcraft
Nortel
Model
Number
WSS
Model
String
WLAN AP-2330A and AP-2330B 2.4 GHz
Antennas
24143-
OUT-10
The "10" refers to the addition of the 10-foot outdoor-rated
LMR-240 extension cable. Output power is compensated for the
addition of the 10-foot plenum rated cable, the lightning
protection circuitry and the 10-foot outdoor rated extension
cable.
24143-
OUT-25
The "25" refers to the addition of the 25-foot outdoor-rated
LMR-240 extension cable. Output power is compensated for the
addition of the 10-foot plenum rated cable, the lightning
protection circuitry and the 25-foot outdoor rated extension
cable.
S241290PN36RSM DR4000086E6 24123 WLAN Directional Patch Panel Array Antenna with an average
gain of 12 dBi, 3-foot cable with a Reverse SMA connector and
either a tilt, wall or pole mounting capability. Antenna is rugged,
easy to install and provides a very symmetrical and uniform 90
degree H-plane and 17 degree E-plane pattern. Designed for long,
wide coverage environments.
24123-
NEMA
To be used with the outdoor NEMA enclosure only. Output
power is compensated for the addition of the 10-foot plenum
rated cable and the lightning protection circuitry.
24123-
NEMA-10
To be used with the outdoor NEMA enclosure only. Output
power is compensated for the addition of the 10-foot plenum
rated cable, the lightning protection circuitry and the 10-foot
outdoor rated extension cable.
24123-
NEMA-25
To be used with the outdoor NEMA enclosure only. Output
power is compensated for the addition of the 10-foot plenum
rated cable, the lightning protection circuitry and the 25-foot
outdoor rated extension cable.
24123-
OUT
Output power is compensated for the addition of lightning
protection circuitry and the 10-foot plenum rated cable.
24123-
OUT-10
The "10" refers to the addition of the 10-foot outdoor-rated
LMR-240 extension cable. Output power is compensated for the
addition of the 10-foot plenum rated cable, the lightning
protection circuitry and the 10-foot outdoor rated extension
cable.
24123-
OUT-25
The "25" refers to the addition of the 25-foot outdoor-rated
LMR-240 extension cable. Output power is compensated for the
addition of the 10-foot plenum rated cable, the lightning
protection circuitry and the 25-foot outdoor rated extension
cable.
