Appendix 75
Nortel WLAN 2300 Series Outdoor Solution Guide
Cushcraft
Nortel
Model
Number
WSS
Model
String
WLAN AP-2330A and AP-2330B
5.0 GHz Antennas
5643-
NEMA-10
To be used with the outdoor NEMA enclosure only. Output
power is compensated for the addition of the 10-foot plenum
rated cable, the lightning protection circuitry and the 10-foot
outdoor rated extension cable.
5643-
NEMA-25
To be used with the outdoor NEMA enclosure only. Output
power is compensated for the addition of the 10-foot plenum
rated cable, the lightning protection circuitry and the 25-foot
outdoor rated extension cable.
5643-OUT Output power is compensated for the addition of lightning
protection circuitry and the 10-foot plenum rated cable.
5643-
OUT-10
The "10" refers to the addition of the 10-foot outdoor-rated
LMR-240 extension cable. Output power is compensated for the
addition of the 10-foot plenum rated cable, the lightning
protection circuitry and the 10-foot outdoor rated extension
cable.
5643-
OUT-25
The "25" refers to the addition of the 25-foot outdoor-rated
LMR-240 extension cable. Output power is compensated for the
addition of the 10-foot plenum rated cable, the lightning
protection circuitry and the 25-foot outdoor rated extension
cable.
S51514WPN36RSM DR4000071E6 5133 WLAN Directional Patch Panel Antenna with an average gain of
13.1 dBi from 5.15 - 5.25 GHz, 13.0 dBi from 5.25 - 5.35 GHz,
13.0 dBi from 5.470 - 5.725 GHz and 12.9 dBi from
5.725 - 5.85 GHz. It has a 3-foot cable with a Reverse SMA
connector. For use in campus or in-building applications. It offers
a very precise and controllable pattern. Must order mounting
bracket separately.
5133-
NEMA
To be used with the outdoor NEMA enclosure only. Output
power is compensated for the addition of the 10-foot plenum
rated cable and the lightning protection circuitry.
5133-
NEMA-10
To be used with the outdoor NEMA enclosure only. Output
power is compensated for the addition of the 10-foot plenum
rated cable, the lightning protection circuitry and the 10-foot
outdoor rated extension cable.
5133-
NEMA-25
To be used with the outdoor NEMA enclosure only. Output
power is compensated for the addition of the 10-foot plenum
rated cable, the lightning protection circuitry and the 25-foot
outdoor rated extension cable.
5133-OUT Output power is compensated for the addition of lightning
protection circuitry and the 10-foot plenum rated cable.
