Appendix 87
Nortel WLAN 2300 Series Outdoor Solution Guide
2 Nortel Order Number: DR4000071E6
z High-Gain Directional Panel Antenna
z Cushcraft Model S51514WPN36RSM
z 5.15 - 5.25 GHz, 13.1 dBi Peak Gain
z 5.25 - 5.35 GHz, 13.0 dBi Peak Gain
z 5.47 - 5.725 GHz, 13.0 dBi Peak Gain
z 5.725 - 5.85 GHz, 12.9 dBi Peak Gain
z Weatherproof housing for indoor/outdoor deployments
z Wall or pole mounting
z Articulating feature allows customizable antenna pattern
z Measures 4” x 4” x 1.4”
