16 Before You Begin
Attach the r ubber feet at the marked locations.
Set the switch on a table or shelf.
ATTENTION
Allow at least 2 inches (5.1 cm) on each side for proper ventilation and at least 5
inches (12.7 cm) at the back for power cord clearance.
Installing the switch in an equipment rack
Required tool: Phillips screwdriver for attaching brackets to the switch.
Rack requirements:
• A space of 2.8 inches for each switch in an EIA or IEC standard 19 inch
(48.2 centimeter) equipment rack.
Nortel Ethernet Routing Switch 2500 Series
Regulatory Information for the Nortel Ethernet Routing Switch 2500 Series
NN47215-100 (323169-B) 02.01 Standard
4.1 19 November 2007
Copyright © 2007, Nortel Networks
.
