Nortel DMS-100 Series Manual

18-2 Power Supply (NT6M71AB)
297-1001-539 Standard 01.03 December 2000
Figure 3-1
DPP Power Supply Assembly
Leave the disk drives untouched for at least 30 seconds after power down
since vibration during power down may damage the disk drive.
DPP system fuses
DPP fuses are located on the front panel of the DPP power supply.
The power supply has the -48 V dc circuit fused. A GMT-type fuse is used.
These fuses have a spring-loaded colored flag which opens when the fuse is
J8
J9 J10
8.5V
15A
4
8
V
1
0
A
Retainer Screw
41
