SCSI circuit pack (NT6M66xx) - Turbo only 9-9
DPP Hardware Component Replacement Guide DPP001 and up
Table 9-2
SCSI circuit pack (A11 and B11) options - part number: NT6M66CA; 1- and 2-Gbyte disk drives
Device type
(number)
Position/setting Function Setting
Factory On-site
Jumper None used
Strap None used
DIP Switch None used
Rotary Switch None used
Switch None used
Note: There are no customer-definable options on this circuit pack. Information is shown for
reference only. Use this data for verification during initial DPP system installation and/or pack
replacement to make sure the replacement pack is set up the same as the pack being replaced.

Nortel DMS-100 Series Specifications

General

Capacity	Up to 100, 000 lines
Features	ISDN support
Redundancy	Yes
Signaling	SS7, ISDN
Power	-48V DC
