vi Contents
297–2011–208 02.01 Standard February 1999
Figures
Figure 1-1 M522 attached to M5316 1-2
Figure 3-1 M522 add-on module key numbering 3-4
Figure 4-1 M5216/M5316 bottom view 4-2
Figure 4-2 Connecting the ribbon cable(s) 4-3
Figure 4-3 Polarized connection detail 4-4
Figure 4-4 Attaching the base (for one M522 module) 4-5
Figure 4-5 Attaching the base (for two M522 modules) 4-5
Tables
Table 3-1 Summary of M522 keys and indicators 3-2
Table 5-1 Ordering information 5-1
