48
Assembly Instructions
Step 3 – Jack to Jack Mount/Tow Bar
• Connect jack to jack mount located on the front end of the tow bar.
• Align jack bracket to jack mount on tow bar. Insert (4) bolts and
thread on (4) locknuts.
• Torque to 41 ft.-lb.
Tools Needed
• 15mm Wrench
• 16mm Wrench
• Torque Wrench
Nut
Bolt
Jack
Mount
Jack
Jack to Tow Bar
Flange Bolt
Qty 4
Jack to Tow Bar
Nyloc Nut
Qty 4
Fasteners Needed from Parts Bag:
