MACHINE COMPONENT IDENTIFICATION
Figure 1 (Ref. 1-11)
00309
Ref. Description Ref. Description
1 Gas Cap with Gauge 9 Air Cleaner Housing
2 6.5 Gallon Fuel Tank 10 Muffler
3 Operation Instructions 11 Decompression Lever
4 Control Panel 12 Warning Decals
5 Oil Filter Access Cover 13 Ignition Fuse
6 Oil Drain Plug 14 Isolation Mounts
7 Oil Fill and Dip Stick 15 Battery Box and Battery
8 Recoil Handle 16 Generator
Figure 2 (Ref. 12-17)
