Throttle Setting Switch & Lamp Switch (right side of meter)
• The left switch defines the throttle adjustment range before the throttle control adjustment. Press and
hold for 15 seconds to set the throttle.
• The right switch controls the two head lights on the front cab.
PTO Control Handle
• Push the handle forward to increase speed.
• Push the handle backward to decrease speed.
• Put the handle in neutral so the PTO is not engaged. The clutch pedal must be pushed all the way in
before using the handle.
Driving Operation
Engine Start-up Preparations
Check the engine oil level in the sump and the gearbox. It’s very important that you keep the oil levels between
the upper and lower lines. Be sure there is sufficient coolant in the radiator and sufficient fuel in the tank.
