HLS PS25 & HLS PS50 User Manual
MN-DT-1305I_B 3
Contents
1 HLS PS Series Installation 4
1.1 Checking the HLS PS for damage 4
1.2 Pre-installation check list 5
1.3 Transient protection 5
1.4 Cleaning 5
1.5 Back Box HLS PS fixing 6
2 Functions and indicators 7
2.1 HLS PS25 and HLS PS50 characteristics 8
2.2 Battery 9
2.3 Fault relay 9
2.4 Control Unit connections 10
2.5 Indicator leds 12
3 Specification 14
