Figure B-3B: NFPA 72-1993 Signaling Systems for Central Station Service
(Protected Premises Unit) and Remote Station Protective Service
NOTI-FIRE 911AC DACT - for connection to a Central Station Receiver or Protected Premises Receiving Unit.
This unit must be installed as illustrated below. For additional information on the 911AC, refer to document
74-06200-005.
All connections between the FACP and 911AC must be in conduit, less than 20' in length in the same room.
NOTE on STD DACT:
Place jumper over pins 2 & 3,
marked DACT, when employ-
ing a DACT. This directs the
control panel to transmit all
trouble conditions except AC
LOSS.
To
Central
Station
Trouble
Supervisory
Alarm
STD DACT
1 3 4 6
JP1
draobrehtoMCA119
mralA
1-4BT7dna6
yllamron
nepo
stcatnoc
3-4BT9dna8
elbuorT
4-4BT01
yllamron
nepo
stcatnoc
6-4BT11
yrosivrepuS
21-1BTMZX421
yllamron
nepo
stcatnoc
dna6-4BTrepmuJ
01-1BTMZX4
