SFP-400B 15124:G1 06/24/97
30
Figure B-3A: NFPA 72-1993 Signaling Systems for Central Station Service
(Protected Premises Unit) and Remote Station Protective Service
NOTI-FIRE 911A DACT - for connection to a Central Station Receiver or Protected Premises Receiving Unit. This
unit must be installed as illustrated below. For additional information on the 911A, refer to document
74-06200-005.
If the NOTI-FIRE 911A is not mounted in the SFP-400B backbox all connections must be in conduit, less than 20'
in length in the same room.
Notes: The Maximum standby load shall be 125 mA. The Standby by Battery Requirement: 24VDC, 7AH Max.
To
Central
Station
(-) Common
Trouble
Supervisory
Alarm
Red
Black
STD DACT
NOTE on STD DACT:
Place jumper over pins 2 & 3, marked
DACT, when employing a DACT. This
directs the control panel to transmit all
trouble conditions except AC LOSS.
1 3 4 6
JP1
24 VDC (+)
27.6 VDC (+)
draobrehtoMA119
mralA
nepoyllamron
stcatnoc
1-4BT7dna6
3-4BT9dna8
elbuorT
nepoyllamron
stcatnoc
4-4BT01
6-4BT11
yrosivrepuS
nepoyllamron
stcatnoc
21-1BTMZX421
dna6-4BTrepmuJ
01-1BTMZX4
CDV42+
5-2BT2
nommoC
6-2BT4
CDV6.72+
daelyrettab)+(1
