INTERSPACE ARM INSTRUCTIONS
Place the arm in the collet facing forward. Carefully put the stylus into the cartridge body and
raise the arm out of the collet. With the small spirit level placed forward on top of the headshell,
set the arm level on top of the record. Lock up the small grub screws with the Allen key provided.
The screws are situated on the right side of the arm board. Check the cartridge alignment with
the protractor provided. Tracking weight is set with the mat in place, but not the record. The bias
can now be set. The plastic weight carrier must hang straight when final adjustment of weight is
achieved.
