Rega Tonearm Instructions
With the cartridge fitted and aligned using the alignment
protractor supplied, ensure that the bias adjustment
slider is set to zero. Screw the balance weight along its
shaft until the stylus is ‘floating’ just 1mm clear of the
record.
The recommended tracking force can now be applied by
rotating the balance weight so that it moves toward the
front of the arm. One half-turn gives 1g of tracking force.
The green plastic plugs on the weight can be used as a
visual aid to achieve this. Always use a force that
corresponds to the upper limit of the cartridge maker’s
recommended range.
Set the bias adjustment slider to the same number as
the tracking force control, i.e.
1 ½g tracking force=1 ½ on the bias slider.
