Nova Voyager

123-1016-004
27
833 Voyager Drill Press Parts List
REF#
PART#
DESCRIPTION
1
C05016
M5×16 Cap Screw
2
8330355
Drill Press Top Cover
3
C08040
M8 Cap Screw
4
8338001
Screw Pad
5
52003
Fan Encoder
6
8330354
Bearing Housing Fan Sensor
7
8338002
Wave Washer
8
6005ZZ
Ball Bearing
9
55430
Location pin (Stator)
10
8339039
DVR Stator
11
55007
DVR Stack
12
8339016
DVR Motor Spindle
13
55050
DVR Motor Spindle Key
14
8339017
DVR Motor Spindle Washer
15
6005ZZ
Ball Bearing
16
8338003
6in Spindle
17
6023LLB
Ball Bearing
18
8338004
Arbor
19
8339012
Drill Press Quill
20
8330353
Headstock Machined
21
8338005
Spring Nut
22
8338006
Spring Cover
23
8338007
Return Spring
24
8338008
Pinion Shaft
25
8338009
Depth Handle
26
C0408
SHCS M4×8
27
6205LLB
Ball Bearing
28
8339041
Mechanical Stop Mount
29
C06020
M6×20 Cap Screw
30
SW06
SLW M6
31
8338010
Quill Lock Bolt
32
C06030
M6×30 Cap Screw
33
8338011
Quill Lock Handle
34
8338012
Quill Pin
35
DX03-009-XX
AC power supply cable
36
8338014
Power Switch
37
CM05010
MSPC-M5×10
38
SZ12016
GSC-M12×16
39
6919011
Basic Sync
40
58018
Controller Board
41
MPB0412
MSPP-M4×12
42
MPB0320
MSPP-M3×20
43
8338019
M20 6-12mm Cable Gland
44
8338020
Quick Release Nut
45
8339042
Mechanical Stop Rod
46
8339031
Mechanical Stop Bracket
47
C05010
M5 Cap Screw
48
8339026
Drill Press Key Pad
49
8338021
JHF16 Sub Body E-Stop
REF#
PART#
DESCRIPTION
50
C05020
SHCS M5×20
51
8338023
Pedometer Cover
52
8339021
Drill Press Depth Pot
53
8339044
Insert Block
54
8339043
Height Sensor Gear
55
598123011
HMI and LCD (Displayer)
56
8339028
Drill Press HMI Encoder
57
8338024
USB-B Type
58
8339014
Drill Press Front Facia
59
8339032
HMI Knob
60
8338025
Base
61
8338026
Hex Bolt M12-1.75×30
62
8338027
Column Base
63
8338028
Column 7-1/4 in
64
8338029
Rack
65
8338030
Rack Ring
66
SZ10010
GSC-M10×10
67
8338032
Clamp Lock handle
68
8338033
Table Bracket
69
8338034
Gear
70
8338035
Worm Gear
71
8338036
Handle Arm
72
8338037
Handle
73
8338038
Gear Shaft
74
SZ08010
GSC-M8×10
75
8338040
Table Arm Bracket
76
8338041
Table Lock handle
77
8338042
Flat Washer 3/4
78
SZ06010
GSC-M6×10
79
BNMZ20040
Hex Bolt M20×40
80
SZ10030
GSC-M10×30
81
8338046
Wood Working Table
82
8338047
Ring
83
C0408
SHCS M4×8
84
FW12
Flat Washer M12
85
55170
EMI filter
