18 CYCLONE & ATOM INSTRUCTION MANUAL
This must be done as soon as the LED turns solid green to
ensure that the speed control learns the Full Brake
position. Moving the trigger gradually and/or hesitating
after the status LED turns solid green may cause less than
the Full Brake position to be learned. Hold the trigger
there until the status LED blinks green.
7. RETURN TRANSMITTER’S THROTTLE TO NEUTRAL
POSITION
The status LED will turn solid red, indicating that proper
programming has been completed.
Your speed control is now set and ready to race!
NOTE: If transmitter settings are changed, it will be necessary to
complete the above sequence again. If problems are experienced
during set-up, turn off the speed control and repeat all steps in
this section.
FIGURE 12 Full Throttle position.
FIGURE 13 Full Brake position.
STEP 5: Speed Control Set-Up (continued)
