14 CYCLONE & ATOM INSTRUCTION MANUAL
BASIC TRANSMITTER ADJUSTMENTS
1. Set HIGH ATV or EPA to maximum setting.
[Controls amount of throw from neutral to full throttle]
2. Set LOW ATV, EPA, or ATL to maximum.
[Controls amount of throw from neutral to full brakes.]
NOTE: Reduce this after performing One-Touch Set-Up to
reduce amount of brakes.
3. Set EXPONENTIAL to zero.
[Controls the linearity of the throttle channel]
4. Set THROTTLE CHANNEL TRIM to middle setting.
[Adjusts the neutral position of the throttle channel]
5. Set MECHANICAL THROW ADJUSTMENT to position
with 2/3 throttle and 1/3 brake throw.
[Adjusts pistol-grip transmitter’s throttle trigger throw]
6. Set ELECTRONIC THROW ADJUSTMENT to 7:3, 70%
forward and 30% brake.
7. Set all other transmitter throttle settings to the transmitter
default settings.
SPECIFIC TRANSMITTER ADJUSTMENTS
The following charts show exact settings for today’s most
popular transmitters used for racing. These settings will
provide maximum linearity and control, and the smoothest
feel for the Cyclone and Atom ESCs.
STEP 4: TRANSMITTER ADJUSTMENTS
Continued
To Next Page
