CYCLONE & ATOM INSTRUCTION MANUAL 15
STEP 4: Transmitter Adjustments (continued)
AIRTRONICS CL-3PS
FIRST: With the trigger in the brake position, set EPA/TH to 90%,
then adjust the TH-EPA-L knob to full counter-clockwise position.
EPA/TH (F/B) ARC-TH REV-TH TH-TRIM
140%/160% 0% NOR
(Middle)
NOTE: After speed control set-up, the TH-EPA-L knob will be
used to reduce maximum push brake.
AIRTRONICS CS-2P
TH-EXPO EPA-HIGH EPA-LOW Rev.Switch TH-TRIM
NOR (cw) (cw) (cw) NOR (Middle)
NOTE: After speed control set-up, the EPA-LOW pot will be
used to adjust maximum push brake.
AIRTRONICS M8
EPA-(BR/HI) EXP-(BR/HI) TRM(SUB) REV TRIM-TH
110%/125% 0%/0% 0 NORMAL (Middle)
NOTE: After ESC set-up,TRIM-TH will be used to adjust coast
brake, and the “+ BRAKE –“ thumb-switch will be used to
reduce maximum push brake (do not go above 110% EPA-BR).
Continued
CW Clockwise
CCW Counter-Clockwise
F Full throttle trigger position
B Full brake trigger position
TRANSMITTER CHART ABBREVIATIONS
To Next Page
