16 CYCLONE & ATOM INSTRUCTION MANUAL
STEP 4: Transmitter Adjustments (continued)
KO PROPO PRECIOUS
SUB•TRIM(TH) REV. SW(TH) Trim: Pos(TH) TH: PUNCH(F/B)
0 REVE 0% 0%/0%
TH: HiPOT TH: BRAKE
H100 B100
NOTE: After speed control set-up, TH-BRAKE will be used to
adjust maximum push brake.
KO PROPO MARS
SUB•TRIM(TH) REVERSE(TH) Et2:Pos(TTrim) TH: PUNCH(F/B)
0 REVE 0 0%/0%
TH: HiPOT Et4:Pos(BRAK)
H100 100
NOTE: After speed control set-up, Et4 will be used to adjust
maximum push brake.
FUTABA 3PJ
SUB.TR TH.N
SERVO REVERSE
ATL ATV (F/B) EXP (F/B)
0% 7:3 REV 100% 90%/110% 0%/0%
NOTE: After speed control set-up, ATL will be used to adjust
maximum push brake.
