NOVAK ATOM AND CYCLONE ESC User Manual

CYCLONE & ATOM INSTRUCTION MANUAL
CYCLONE & ATOM INSTRUCTION MANUAL 33
Red Power Wire
(Motor and battery
positive)
Trail excess wire
off antenna mast.
(Do not cut or coil)
(+)(–)
Blue Power Wire
(Motor negative)
LED
One-Touch Button
Mount ON/OFF
Switch where it will
be easily accessible.
(
–)
(
+)
Minimum Brake
Adjustment Pot
Black Power Wire
(Battery negative)
FIGURE 11
Keep Receiver and Antenna
away from motor, servo,
battery, and power wires.
Three 0.1 µ F
Capacitors
External
Schottky Diode
Data Link™
Input Harness
Power Capacitor
with heat shrink
Blue FET Servo Wire
Brake Light Wires
(Cyclone only)
CYCLONE & ATOM
HOOK-UP PHOTO
(Cyclone shown)
Twist motor wires
to reduce Radio
Frequency (RF) noise
