The following table describes the LED operation.
LED Description
OBD
(Red)
l The OBD LED flashes at a fast rate when the unit is first connected to the OBD
port for power.
l Once a protocol is discovered through the OBD port, the LED flashes at a slow
rate.
GPS
(Yellow/Amber)
l The GPS LED flashes at a fast rate when the unit is acquiring a satellite fix.
l Once a fix is acquired, the LED flashes at a slow rate.
NETWORK
(Green)
l The NETWORK LED flashes at a fast rate when the unit is finding cellular
coverage.
l Once cellular coverage is found, the LED flashes at a slow rate.
BLUETOOTH
(Blue)
The BLUETOOTH LED indicates bluetooth connectivity. (Not currently supported)
MT 3060 User Guide 10
