SysEx command summary
Each of the following SysEx messages has the same header:
Hex Version: F0h 00h 20h 29h 02h 0Eh
Decimal Version: 240 0 32 41 2 14
Parameter Name
Command
Code
Value 1
Value 2
Value 3
Repeatable?
Select
Layout
00h (0)
<layout>
-
-
-
DAW Fader Setup
01h (1)
00h (0)
<orientation>
<fader>
<fader> only
LED
Lighting
03h (3)
<colourspec>
-
-
<colourspec>
Live/Programmer
Toggle
0Eh (14)
<mode>
-
-
-
DAW /
Standalone
10h (16)
<mode>
-
-
-
Stop Faders for
Bank
19h (25)
<bank index>
-
-
-
Mode Hierarchy Table
Live Mode
Programmer Mode
DAW Mode
(DAW Mode message sent
to enable Session Mode)
Standalone Mode
(default when turned on)
Functionality available:
Only the Programmer Layout
Functionality available:
Session Mode, DAW Faders
+ all Standalone Mode
functionality
Functionality available:
Note Mode, Chord Mode,
Custom Modes, Sequencer
