Chapter2 Connection
Manual of NVEC400
- 11 -
4 OUT9 Output Port9
5 OUT11 Output Port11
6 GND Ground for output
7 TXD2 TXD for USART
8 GND2 Ground for USART
9 OUT5 Output Port5
10 OUT7 Output Port7
11 GND Ground for output
12 OUT10 Output Port10
13 OUT12 Output Port12
14 VCC5 5V supply
15 RXD2 RXD for USART
Table 2-1.
General output interface
definition
www.nvcnc.net
