Noyes OLS Series User Manual

16
The current measurements are stored in the next available memory location (next Fiber) of the current 5.
File.
Recall Mode: To View Stored Records
Press and hold the 1. Arrow/File key to enter File mode and select the desired File to view.
Press the Recall key to display the Recall mode screen.2.
Once the Recall key is pressed and before entering the Recall mode screen, the number of currently 3.
open file
A
and number of fibers
B
stored in the current file will flash for ~ 1.5 seconds.
FILE
FIBS
22
4
A
B
Once in the Recall mode screen, the display changes to show the following data: 4.
0.22 0.22
1310 1310
dB dB
nm
4 4
FIBR FIBR
WAVE ID
A
B
E
C
D
nm
Hz
A
- Fiber number,
B
- Wavelength,
C
- Stored test result,
D
- WAVE ID icon if WAVE ID was active when the measurement was taken,
E
- Hz icon, if Tone was active when the measurement was taken.
Use the 5.
/ arrow keys to increment/decrement the fiber number and view the test result stored in
this location.
Press and hold the • arrow key to go to the last fiber.
Press and hold the • arrow key to go to the first fiber.
For multiple-Wave test results, press the wavelength • key to change wavelengths.
Press the Recall key to exit.6.
Press the Store key to exit the File mode.7.
Note: you can go directly to the Recall mode for the current file by pressing the Recall key from the Test
screen.
OPM5 Models
