25
OLS7-3 Features
Power key1. - Press this key to turn the OLS7-3 on or off. When the unit is turned on, it returns to the
last operating condition it was in prior to being turned off.
Power port2. (located on the top panel) - This is the interface for an AC power adapter.
External Power indicator3. - Lights up, whether the unit is on or off, when the correct AC power
adapter is connected.
Low Battery indicator4. - Lights up when a Low Battery condition exists; batteries require
replacement.
Output port 5. - Universal Connector Interface (UCI). Accepts swappable SC connector (ST, FC, and LC
connector styles are available).
Active Output indicators -6. The Active Output indicators light up when the corresponding output port
is on.
Wavelength 7. - l key - Wavelength select key changes the active output wavelength(s) as indicated
below for each operational mode.
WAVE ID Mode (WAVE ID indicator on)
Press the • l key to select wavelengths in the following sequence:
OLS7-3 Triple Wavelength Laser Source
