NPG DTR-126 - Page 22

User´s Manual English
DTR 126 22
Terrestrial
Tuner/Demodulator
Input Frequency
Standard
Channel Bandwidth
OFDM Spectrum
Modulation Mode Guard
Interval Modes
FEC Modes Rate
VHF:177,5MHz to 227,5MHz
UHF:474 MHz to 858MHz
DVB-T (ETSI 300 744)
6MHz, 7MHz, 8MHz
2k/8k-carrier hierarchical
64QAM:-78.5dBm～-8.75dBm；16QAM:-84.1dBm～-8.75dBm；QPSK:-
90.3dBm～-8.75dBm
System
CPU
Transport
Flash Memory
SDRAM
Tuner Type
Cheertek CT216T/CT216TH
DVB Demultiplexer
8MB SRD
4X16
MAXLINER5003 Onboard Tuner
Video
Standard
Field/Frame Rate Output
mode supported
Aspect Ratio
MPEG-1 ISO/IEC 13818 and
MPEG-2 MP@ML
50/25Hz
720x576i
4:3, 16:9 with letter box and Full Screen
supported
Audio
Standard
Sampling Frequency Digital Audio Out
Format
MPEG-1 ISO/IEC 11172-3 layers 1 and 2
MPEG-2 ISO/IEC 13818-3 Dolby Digital
AC-3
32, 44., 48kHz IEC-60958/IEC-61937
Rear panel
interface
RF input / Loop through
TWO Scart Outputs
IEC Type 75 Ohm
TV/VCR
User Interface
Front Panel
LED: Red STANDBY；Green LOCK
Software upgrade
Firmware Upgrade over USB
Power
Main input voltage Operating Frequency
Power consumption
220V/240VAC
50/60Hz Normal operation 6W
Standby mode 1W
Max. 8W
Environmental
Condition
Operating Temperature
Dimension(WxDxH)
Weight
0~40 ℃ Humidity <95%
220X122X38(mm)
0.71kg
