NSD Varicam VS-5E-1 User Manual

●
VRE-P028SAC Unit: mm
●A-13●
7
±0.5
3
±0.5
15±0.5
1.5
±0.1
2
35
1.5
0
-0.1
φ28
φ16
φ28
0.5
(10)
φ25
(φ5)
(φ11)
φ18h7( )
0 -0.018
φ5h7( )
0 -0.012
25
2000(42)
ROBOTIC CABLE
3P-RBT
R04-PB9M5.2A
CONNECTOR
●
Mounting hole dimensions for Servo mount.
φ36
±0.2
φ18
H7
( )
＋0.018
−0
φ45
3×M3 (hole evenly spaced);
Max. mounting fixture diameter
Depth: 4mm or more
