NSK SGS Series User Manual

25
EN FR
11. Specifications
Model SGS-ES SGS-E2S SGA-ES SGA-E2S
HandpieceType Straight 20°Angle
AllowableMax.Speed 40,000min
-1
80,000min
-1
40,000min
-1
80,000min
-1
Max.RotationSpeed(Motor) 40,000min
-1
Max.RotationSpeed
(Handpiece)
40,000min
-1
80,000min
-1
40,000min
-1
80,000min
-1
GearRatio 1:1DirectDrive 1:2Increasing 1:1DirectDrive 1:2Increasing
BurType ShortSurgicalBursØ2.35xL70mm
ChuckLength 55.5mm 53mm 55.5mm 53mm
Max.WorkingPartDiameter Ø7.0mm Ø3.0mm Ø7.0mm Ø3.0mm
WaterPressure Min.50ml/min(0.2MPa(2.0bar))
UseEnvironment Temperature:10-35°C,Humidity:30-75%(NoCondensation)
TransportationandStore
Environment
Temperature-10-50°C,Humidity:10-85%,Pressure:500-1,060hPa
SGS.SGA_EN_180111.indd 25 2018/01/12 19:07:18
