4-2 Disconnecting

Hold the Motor and the Handpiece, then pull apart.

5. Mounting and Removing the Bur

5-1 Mounting the Bur

1) Turn the Bur Lock Ring in the direction of the "

" mark until it clicks. (Fig. 2)

2) Insert the bur fully into the chuck then turn the Bur Lock Ring in the direction of the "

" mark

until the " " mark and the " " mark align with a click.

3) Confirm that the bur is secure by gently pulling and pushing the bur.

Fig. 2

Bur Lock Ring

Open

Chuck Closed

Chuck Open

CAUTION

• Do not connect or disconnect the handpiece until the motor has completely stopped.

• Connect ONLY to E type motors (ISO 3964) with the Max. Speed of 40,000 min

-1

or less.

SGS.SGA_EN_180111.indd 6 2018/01/12 19:07:13
