NSK Ti-Max X - Performance Specifications

X500L X500 X600L X650L X600
X700L X700
Model
Head Type
Miniature Head Standard Head Torque Head
Rotation Speed
390,000 ~ 450,000min
-1
380,000 ~ 440,000min
-1
300,000 ~ 360,000min
-1
Drive Air Pressure
0.25MPa (2.5kgf/cm
2
) ~0.3MPa (3.0kgf/cm
2
)
Chuck Type
Push Button Chuck
Optics
ø10.3 x 11.7 mm
ø11.2 x 13.6 mm ø13.2 x 13.6 mm
Head Size Diameter x Height
Burs
Size: ISO1797-1 Type3 ø1.59~1.60
Friction Grip Standard ShankFriction Grip Short Shank
—
Cellular Glass Rod
—
Cellular Glass Rod
—
Cellular Glass Rod
Performance specifications
3
