NSK Ti-Max X500L User Manual

CONNECTION (Fig.1)
To connect the handpiece to the coupling align the handpiece to the
coupling and push together (per the coupling manufacturers instructions).
DISCONNECTION (Fig.1)
Release the handpiece from the coupling (per the coupling manufacturers
instructions) and remove the handpiece.
NSK COUPLING : Pull back Connector Ring to release the handpiece.
First make sure the manufacturer’s coupling is firmly attached to the
handpiece tubing and the drive air pressure is correct.
Fig. 1
Handpiece
NSK Coupling
Connector Ring
Connection / Disconnection to the Coupling
5
ENGLISH FRENCH GERMAN SPANISH ITALIAN

NSK Ti-Max X500L Specifications

General

Brand	NSK
Model	Ti-Max X500L
Category	Dental equipment
Language	English
