Caprice │ Installation and Operation Instructions - Introduction C 85-340
Natural Draft Applications
Natural Draft Applications - All Caprice models are certified as Natural Draft boilers
which require a “Chimney System”. The exhaust gases must be vented directly to the
chimney. Failure to follow these instructions will result in serious injury or death.
Blocked Vent Switch - All Natural Draft Caprice boilers require a Blocked Vent Switch
which is factory supplied and packaged with the burner kit and is mandatory in Canada.
The Block Vent Switch must be field installed as per the instructions in this manual and the manufacturers
instructions included with the switch. Failure to follow the specified instructions may result in fire, property
damage, personal injury, or death.
Table 1-1 Caprice Boiler Packages (Natural Draft)
Burner kit Contents (Natural Draft)
1
Boiler manual packaged with the Burner Kit.
2
Nozzle size included in Burner Kit. See below, “Attention: Nozzle Sizes”.
3
Burner and blast tube comes assembled c/w nozzle specified in this table. Nozzle may need to be changed depending on boiler output.
4
Models C150 and C180 no longer meet minimum efficiency regulations.
Nozzle Sizes - The nozzle sent with each respective boiler burner kit is for the minimum
firing rate specified for that burner. To obtain a different firing rate, replace the factory
supplied nozzle with the appropriate nozzle that meets the desired output. Refer to Tables 2-1 to 2-2 in Section
2.0 for nozzle specifications and performance ratings for Natural Draft boilers.
Manufacturer’s Instructions - For complete instructions on installation and control
operations, refer to the manufacturer’s instructions included with the Fuel Smart
HydroStat 3250, Burner Package, and Blocked Vent Switch.
