Caprice │ Installation and Operation Instructions - Parts List C 85-340
36
12.0 PARTS LIST
For a list of parts that corresponds to the item numbers in the callouts, refer to Table 12-1. Note that some item
numbers may appear more than once in the parts list depending on which model number is being referenced.
Building Owners - Replacement parts are available from your stocking wholesaler. Contact your local Installer
or Wholesaler for assistance with parts.
Wholesalers - Contact NY Thermal Inc. directly when ordering replacement parts, 1-506-657-6000.
Installers - Contact NY Thermal Inc. directly if technical assistance required, 1-800-688-2575.
Figure 12-1 Boiler, Coil, and Jacket
74
10
1
17
9
7
6
8
12
14
11
5
15
16
13
3
2
Item 10: Blocked Vent
Switch is applicable to
Natural Draft models only,
mandatory in Canada.
4
18
