FTV I&O Manual │General Venting
19
Sidewall Venting Options – Direct Vent Installation
Figure 4-4 (a) Two-pipe Termination (Sidewall)
Figure 4-4 (b) Low Profile Termination (Sidewall)
Figure 4-4 (c) Concentric Termination (Sidewall)
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
Exhaust
Inlet
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
Exhaust
Inlet
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
Exhaust
Inlet
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
Exhaust
Inlet
