Trinity │Installation and Operation Instructions Tft Series
28
Boiler Condensate Drain
Inlet Gasket
Ball-float

Figure 6-1 Condensate Drain Piping

Inlet Gasket
Outlet
Corrugated Outlet Tube
Outlet Retaining Nut
Outlet Gasket
Inlet
Cleanout Cap
Condensate Trap
Inlet Retaining Nut
firmly tightened

Corrugated Outlet Tube routed to household
drain, condensate pump or neutralizer (no strain
applied on tubing or condensate drain assembly)

