Trinity │Installation and Operation Instructions Tft Series
46
Figure 10-4(a) Tft60-110 Head Loss Curve
0
1
2
3
4
5
6
2 4 6 8 10 12
Flow Rate (US gpm)
Head Loss (ft)
Figure 10-4(b) Tft154-285 Head Loss Curve
0
2
4
6
8
10
12
14
6 8 10 12 14 16 18 20 22 24
Flow Rate (US gpm)
Head Loss (ft)
Figure 10-4(c) Tft340-399 Head Loss Curve
0
2
4
6
8
10
10 12 14 16 18 20 22 24 26 28 30 32 34 36 38
Flow Rate (US gpm)
Head Loss (ft)
