NTI Trinity Tft285 - Page 92

Trinity │Installation and Operation Instructions Tft Series
92
Item
Part #
Models
Description
26
85785
Tft201
Heat Exchanger ASME
26
84456
Tft155, Tft175, Tft200,
Tft250, Tft285
Heat Exchanger ASME
26
85346
Tft340
Heat Exchanger ASME
26
84459
Tft300, Tft399
Heat Exchanger ASME
27
84505
Tft285-399
Tube Strap
27
84504
Tft60-250
Tube Strap
28
84637
Tft60-110, Tft155-399
Grommet, Flue Sensor, Tft-series
28
85208
Tft154
Grommet, Flue Sensor, Tft154, Vmax
30
83510
Tft60-399 (pre s/n 15140
and post s/n 119299)
Condensate Trap (pre s/n 15140 and post s/n 119299)
30
85119-1
Tft60-399 (s/n 15140 to
119299)
Condensate Trap (s/n 15140 to 119299)
31
84479
Tft60-399
Elbow, Brass, Street 90, 3/4"
32
84545
Tft60-110
Burner Plate Gasket
32
84549
Tft155-285
Burner Plate Gasket
32
84554
Tft300-399 (pre s/n 20916)
Burner Plate Gasket
33
84544
Tft60-110
Burner Plate Ceramic Disc
33
85455
Tft154
Burner Plate Insulation & Gasket
33
84551
Tft155-285
Burner Plate Ceramic Disc
33
84556
Tft300-399 (pre s/n 20916)
Burner Plate Ceramic Disc
33
85483
Tft340-399 (post s/n 90974)
Burner Plate Insulation & Gasket
34
84543
Tft60-110
Burner Plate
34
85456
Tft154
Burner Plate
34
84550
Tft155-285
Burner Plate
34
84555
Tft300-399 (pre s/n 20916)
Burner Plate Tft300-399
34
85484
Tft340-399 (post s/n 90974)
Burner Plate Tft340-399
35
84214
Tft60-399
Grommet, Diaphragm, 1/2"
36
82762-1
Tft60-399
Flame Rod Lx/Ti/Ts/Tft (60-500) (Includes P/N: 82774)
37
82099
Tft60-250
1-1/2" MJ Coupling
37
82100
Tft285-399
2" MJ Coupling
38
82615
Tft60-110
Round Mesh Vent Screen, 2"
39
84557
Tft60-110
Air Inlet Assembly
39
85387
Tft154
Air Inlet Assembly
39
84558
Tft155, Tft175, Tft200,
Tft250
Air Inlet Assembly
39
85821
Tft201
Air Inlet Assembly
39
85816
Tft285
Air Inlet Assembly
39
84559
Tft300-399
Air Inlet Assembly
40
83718
Tft60-399
Hose Clamp, 1-1/16 to 1-1/2”
41
84437
Tft60-110
Flue Outlet Adapter SS 3" (304065 D)
41
85132
Tft154
Flue Outlet Adapter PP 3"
41
84438
Tft155-285
Flue Outlet Adapter SS 3" (304066)
41
84451
Tft300-399
Flue Outlet Adapter SS 4" (304081)
42
84436
Tft60-110, Tft155-285
Air Inlet Adapter SS 3"
42
85133
Tft154
Air Inlet Adapter PP 3"
42
84450
Tft300-399
Air Inlet Adapter SS 4"
43
85826
Tft60-399 (post s/n 119299)
Condensate Drain Adapter Tube (post s/n 119299)
43
85107 (85119-1)
Tft60-399 (s/n 15140 to
119299)
Condensate Drain Adapter Tube Kit (s/n 15140 to
119299)
44
84497
Tft60-110, Tft155-399
Exhaust Test Plug, EPDM
45
84566
Tft60-285
Wall Mount Bracket
45
84567
Tft300-399
Wall Mount Bracket
