Table 4-5 Optional Vent Termination Kits
Description
Vent
Size
Supplier p/n
Figure
Vent Material
Compatibility
Vent Option
Roof
Wall
IPEX Low Profile
(Wall)
7
2”
196984
4-4(b), 4-6(c)
PVC/CPVC
7


3”
196985 (NTI p/n 84357)
IPEX Concentric
(Wall/Roof)
4,5,6,7
2”
196125
4-4(c), 4-5(c),
4-6(b), 4-7(b)


3”
196116 (NTI p/n 82666)
197117
PolyPro® Concentric
(Wall)
2-3”
2PPS-HK, 3PPS-HK
4-4(c), 4-6(d)
PolyPro®
Polypropylene


PolyPro® Concentric
(Roof)
2-3”
2PPS-VK, 3PPS-VK
4-5(c), 4-7(c)


InnoFlue® Flush Mount
(Wall)
2-3”
ISLPT0202, ISLPT0303
4-4(b), 4-6(c)
InnoFlue®
Polypropylene


InnoFlue® Concentric
(Wall)
2-3”
(ICWT242 & ICTC0224),
(ICWT352 & ICTC0335)
4-4(c), 4-6(d)


InnoFlue® Concentric
(Roof)
2-3”
(ICRT2439 & ICTC0224),
(ICRT3539 & ICTC0335)
4-5(c), 4-7(c)


Z-DENS® Concentric
(Wall)
2-3”
2ZDHK2, 2ZDHK3
4-4(c), 4-6(d)
Z-DENS®
Polypropylene


Z-DENS® Concentric
(Roof)
2-3”
2ZDVK2, 2ZDVK3
4-5(c), 4-7(c)


Notes:
1
Instructions included with termination kits contain detailed assembly and installation instructions.
2
Clearance requirements in this manual supersede those of the instructions included with the vent terminal.
3
Piping MUST be secured to the vent terminal during installation.
4
IPEX Concentric Terminal MUST be cemented together and to the vent pipes during installation.
5
Vent Screens provided with boiler may be used with the IPEX Concentric Vent Kits; otherwise use IPEX vent screens (2
in. vent screen p/n 196050; 3 in. vent screen p/n 196051 – each sold separately).
6
IPEX Low Profile and Concentric kits (excluding p/n 197117) are constructed out of ULC S636 approved PVC; check
with your local authority for the acceptance of PVC as a venting material prior to use.
7
IPEX Concentric kits can be shortened to fit the requirements of the installation; see instructions included with the kit for
more details.
PVC In Canada - Authorities in some jurisdictions may not allow the use of any PVC
venting materials with condensing boilers; check with the local safety inspector to verify
compliance prior to installing a PVC Concentric Vent Kit with a Trinity Tx.
