Introduction │ Tx I&O Manual
Failure to use the appropriate Natural to LP Conversion Kit and Orifice when operating
the Trinity Tx to operate with Propane will result in extremely dangerous burner
operation leading to property damage, serious injury or death. Refer to section titled
ATTENTION: LIQUEFIED PETROLEUM (LP) PROPANE for applicable
conversion kit and LP orifice numbers.
ATTENTION: LIQUEFIED PETROLEUM (LP) PROPANE
The Trinity Tx is factory set to operate with Natural Gas. BEFORE OPERATING WITH PROPANE, the
specified LP Conversion Kit and Orifice must be installed to convert the boiler so it will operate safely with
LP Propane. The correct kit and LP orifice is listed below (Each kit comes with conversion instructions).
Liquefied Petroleum (LP) propane gas is heavier than air; therefore, it is imperative that your Trinity Tx boiler
is not installed in a pit or similar location that will permit heavier than air gas to collect. Local Codes may
require boilers fueled with LP gas be provided with an approved means of removing unburned gases from the
room. Check your local codes for this requirement.
Natural to LP Propane Conversion Kit_
Model Number Kit Number LP Orifice
Tx51 84867-1 3.5mm
Tx81 84867-2 3.8mm
Tx101 84867-3 4.2mm
Tx151(C) 84867-4 5.05mm
Tx200(C) 82650-1 6.2mm
Exhaust Vent / Air-Inlet Piping
The Trinity Tx is certified as a “Category IV” boiler, and requires a “Special Venting
System” designed for pressurized venting. The exhaust gases must be piped directly to
the outdoors using the vent materials and rules outlined in these instructions. Failure to
follow these instructions will result in serious injury or death.
