NuAire XBOXER XBC Series User Manual

21. 07. 20. Leaflet Number 671748
43
XBOXER XBC 10-65 Ecosmart Connect (CO) Control
12.0 Appendix To Software Strategy
12.1 BACnet Object List (By Instance Number)
LCD Browser
Page
Name Description Type BACnet Object
Instance Number
Units Default
Value
1 Supply Air Temp (B) The supply air temperature AI 10005 Degrees-Celsius N/A
1 Fresh Air Temp (H) The fresh air temperature AI 10008 Degrees-Celsius N/A
1 Extract Air Temp (C) The extract air temperature AI 10011 Degrees-Celsius N/A
2 RM199 Humidity The Humidity at RM address 199 AI 10017 Percent-Relative-Humidity N/A
2 RM199 Temp The temperature at RM address 199 AI 10029 Degrees-Celsius N/A
2 IN4 The 0-10 voltage at input 4 AI 10032 Volts N/A
2 IN5 The 0-10 voltage at input 5 AI 10035 Volts N/A
3 RM200 Temp The temperature at RM address 200 AI 10050 Degrees-Celsius N/A
3 RM200 Humidity The Humidity at RM address 200 AI 10053 Percent-Relative-Humidity N/A
3 RM201 Temp The temperature at RM address 201 AI 10065 Degrees-Celsius N/A
3 RM202 Temp The temperature at RM address 202 AI 10068 Degrees-Celsius N/A
4 RM203 Temp The temperature at RM address 203 AI 10071 Degrees-Celsius N/A
4 RM201 Humidity The Humidity at RM address 201 AI 10077 Percent-Relative-Humidity N/A
4 RM202 Humidity The Humidity at RM address 202 AI 10092 Percent-Relative-Humidity N/A
4 RM203 Humidity The Humidity at RM address 203 AI 10107 Percent-Relative-Humidity N/A
5 RM212 CO2 The CO2 at RM address 212 AI 10137 Parts-Per-Million N/A
5 RM213 CO2 The CO2 at RM address 213 AI 10140 Parts-Per-Million N/A
5 RM214 CO2 The CO2 at RM address 214 AI 10143 Parts-Per-Million N/A
5 RM215 CO2 The CO2 at RM address 215 AI 10146 Parts-Per-Million N/A
6 Output 4 Configurable output 4 (OUT4) AO 10173 Percent N/A
6 Extract Fan Output The 0-10v signal to the extract fan AO 10176 Volts N/A
6 Heating Output The 0-10v signal to the heating output AO 10179 Percent N/A
6 Supply Fan Output The 0-10v signal to the supply fan AO 10182 Volts N/A
7 RM199 Setpoint The setpoint at RM address 199 AV 10023 Degrees-Celsius N/A
7 RM200 Setpoint The setpoint at RM address 200 AV 10074 Degrees-Celsius N/A
7 RM201 Setpoint The setpoint at RM address 201 AV 10083 Degrees-Celsius N/A
7 RM202 Setpoint The setpoint at RM address 202 AV 10098 Degrees-Celsius N/A
8 RM203 Setpoint The setpoint at RM address 203 AV 10113 Degrees-Celsius N/A
8 Alarm Delay Alarm hold off period AV 10262 Seconds 10
8 Auto-Run on Max-Time Maximum Run-on Max Time AV 10263 Seconds 900
8 Auto-run-on Scale Factor Scale Factor for automatic run-on time AV 10264 No units 2
9 CO2 Target Target CO2 Value AV 10265 Parts-per-million 650
9 Deadband Dead band for temp control AV 10266 Degrees-Celsius 3
9 Run-on (Enable) Run-on timer value AV 10267 Seconds 0
9 Extract Fan Max Individual fan maximum speed setting AV 10268 Percent 100
10 Extract Fan Min Individual fan minimum speed setting AV 10270 Percent 20
10 Run-on (Boost) Boost run-on time AV 10272 Seconds 0
10 Supply Fan Boost Speed Supply Fan boost speed AV 10273 Percent 100
10 Frost Prot. Fan Off Minimum time the supply fan will stop in a frost
protection state
AV 10274 Seconds 300
11 Frost Prot. Temp Supply temperature at which frost protection becomes
active
AV 10275 Degrees-Celsius 4
11 Heat Boost Setpoint Heater Boost Setpoint AV 10276 Degrees-Celsius 35
11 High Temp Alarm Supply temp which will trip the high supply alarm AV 10277 Degrees-Celsius 50
11 Humidity Target Relative Humidity Target AV 10278 Percent-Relative-Humidity 50
Please note: The numbers in parentheses before each multi state object is the enumerated object value for use with BACnet browsers.
