USER’S GUIDE
1. Contents of the product
 trail camera
 mounting strap
 USB cable
 user’s guide
2. Presentation of the product
3-position switch
Lens
Infrared LEDS
Passive infrared
sensor (PIR)
Strap holes
OK key
Notch to open
the battery
compartment
Figure 1: front view
Figure 2: back view
Figure 3: bottom view
Figure 4: internal view
Screw thread for tripod
LCD screen
SD card slot
UP key
DOWN key
External power port cover
External power port
USB port
Rope to open
the battery
compartment
