en-938821/2 8 - 47
8
Operator-Accessible Maintenance
The peripheral started transmitting data too soon
The CNC must be ready to receive data before the peripheral start transmitting or the CNC does not recognise the
beginning of the file and displays the message:
WRONG SEGMENT REFERENCE
WRONG SEGMENT IDENTIFIER
Repeat the verification procedure.
Exit from the procedure
In answer to the question:
VERIFY
? (Y,N) ❚
Select not to verify the programmes. ☞
N
Return to the "RESIDENT MACROS" menu. ☞
EXIT
8.8.8 Loading Programmes in Protected Area
The purpose of loading is to install backup programmes in the protected area:
- individually or globally in the case of programmes from other systems (job reference not indicated),
- globally from the backup copy of the protected area performed on the same system (job number verification).
When the programmes have been loaded, they retain their original characteristics:
- same protected area,
- locked programmes remain locked,
- the area password is not affected by loading.
Requirements
CNC connected to the peripheral (See C.2).
Peripheral ready to transmit binary data (See peripheral manual).
CNC reception baud rate (See 8.3) conforming to the peripheral transmission baud rate.
"RESIDENT MACROS" menu displayed (See 8.8).
Actions
Select "LOAD". ☞
$
4
