NUM 1060 W - B.1 Miscellaneous Errors and Machine Errors

List of Errors
en-938821/2 B - 3
B
B.1 Miscellaneous Errors and Machine Errors
Error No. Meaning of the error
1 Unknown character / Axis not recognised by the system
Too many digits after a function
Presence of a sign after a function which does not allow signs
Truncated block signalled by ? via CLOSE in drip feed mode
2 Unknown G function or a mandatory argument missing after the G
3 Attribute of a G code wrongly positioned
4 Option not enabled or option parameter conflict:
Structured programming, RTCP, synchronised axes, etc.
5 Geometric option programming not enabled
6 Polynomial interpolation option missing coefficient table full
7 Error in programming movements parallel to inclined axes (grinder):
- Programming is not in plane G20
- Interpolation is not in G00 or G01
- X is not programmed after G05
- X and Z are not programmed after G07
8 Tool correction number too high
9 A sequence of too many non-working blocks - Endless Loop
10 In PLC terminal access: Bus exchange error
11 In PLC terminal access: Bus initialisation error or exchange inhibited
12 In PLC terminal access: Rack parameter error
13 In PLC terminal access: No such card
14 Inclined plane option missing
PLC boundary access: channel missing
15 Invalid line configuration
16 Error in RTCP activation
17 End of block in a comment - close bracket missing
18 ∗ Servo error: P50 too small
20 No M02 at the end of the programme
Blocks not made executable in a cycle called by a G function
21 Blank definition incoherent in 3D mode
24 Error in inclined plane declaration
- Function reactivated when already active
- Function argument declaration incomplete
- Pivot point axis does not exist or is not servo-controlled
- Incoherent value in one of the matrix terms
25 Subroutine or sequence number does not exist
26 Too many subroutine nesting levels
27 Radius offset: In G52 machine origin programming / With taper threads
28 Syntax error in CCSPD or index table radius definition
G96 must be followed by S / G97 must be followed by S / initial radius cannot be determined
X or U not programmed in this block or a previous block
29 No range programmed for CCSPD / No range compatible with S in G97:
No range search option: S not included between min. and max. values of the range programmed
With range search option: S does not belong to any range
30 Line error detected
∗ Machine error. Caution: For this type of error, a CNC reset causes a general reset (CNC reset + PLC reset)
