NUM 1060 W - Page 381

Use of Peripherals
en-938821/2 C - 23
C
C.2.2.2 Numerical Control / Peripheral Device Connection
Connection to GNT tape reader
TAPE READER NUM CNC
25-contact male Sub.D 9-, 15- or 25-contact male Sub.D
connector connector
DTR DCD
TD RD
DSR DTR
GND GND
CTS RTS
CTS
Signal 25-contact Sub.D (GNT side)
TD 2
DTR 20
GND 7
DSR 6
CTS 5
Connection to ZIP 30 terminal
TERMINAL NUM CNC
25-contact male Sub.D 9-, 15- or 25-contact male Sub.D
connector connector
DTR DCD
TD RD
RD TD
GND GND
CTS RTS
DCD CTS
Signal 25-contact Sub.D (ZIP 30 side)
TD 2
RD 3
DTR 20
GND 7
CTS 5
DCD 8
