Appendix D Information Concerning
the Exchange Area Bit
The table below gives the Ladder addresses of the bits in the exchange area corresponding to the mnemonics of the
data mentioned in the manual.
Mnemonic Identification Address of the bit
AUTAV General feed authorisation %W4.0 (bit of value 1 of byte %W4.B)
CRM1 M function report - group 1 %W100.5 (bit of value 32 of byte %W100.B)
CRM2 M function report - group 2 %W200.5 (bit of value 32 of byte %W200.B)
CRM3 M function report - group 3 %W300.5 (bit of value 32 of byte %W300.B)
CRM4 M function report - group 4 %W400.5 (bit of value 32 of byte %W400.B)
CRM5 M function report - group 5 %W500.5 (bit of value 32 of byte %W500.B)
CRM6 M function report - group 6 %W600.5 (bit of value 32 of byte %W600.B)
CRM7 M function report - group 7 %W700.5 (bit of value 32 of byte %W700.B)
CRM8 M function report - group 8 %W800.5 (bit of value 32 of byte %W800.B)
C_AUTAV1 Feed authorisation - group 1 %W100.0 (bit of value 1 of byte %W100.B)
C_AUTAV2 Feed authorisation - group 2 %W200.0 (bit of value 1 of byte %W200.B)
C_AUTAV3 Feed authorisation - group 3 %W300.0 (bit of value 1 of byte %W300.B)
C_AUTAV4 Feed authorisation - group 4 %W400.0 (bit of value 1 of byte %W400.B)
C_AUTAV5 Feed authorisation - group 5 %W500.0 (bit of value 1 of byte %W500.B)
C_AUTAV6 Feed authorisation - group 6 %W600.0 (bit of value 1 of byte %W600.B)
C_AUTAV7 Feed authorisation - group 7 %W700.0 (bit of value 1 of byte %W700.B)
C_AUTAV8 Feed authorisation - group 8 %W800.0 (bit of value 1 of byte %W800.B)
C_FMEXT1 End of external movement - group 1 %W100.1 (bit of value 2 of byte %W100.B)
C_FMEXT2 End of external movement - group 2 %W200.1 (bit of value 2 of byte %W200.B)
C_FMEXT3 End of external movement - group 3 %W300.1 (bit of value 2 of byte %W300.B)
C_FMEXT4 End of external movement - group 4 %W400.1 (bit of value 2 of byte %W400.B)
C_FMEXT5 End of external movement - group 5 %W500.1 (bit of value 2 of byte %W500.B)
C_FMEXT6 End of external movement - group 6 %W600.1 (bit of value 2 of byte %W600.B)
C_FMEXT7 End of external movement - group 7 %W700.1 (bit of value 2 of byte %W700.B)
C_FMEXT8 End of external movement - group 8 %W800.1 (bit of value 2 of byte %W800.B)
C_UNIT Units of displayed dimensions
(mm or inches) %W4.5 (bit of value 32 of byte %W4.B)
NARFIB No stop at end of block %W4.3 (bit of value 8 of byte %W4.B)
