33
SPECIFICATIONS
INPUTS: Line: 10kΩ input impedance
85mV rms sensitivity (for 1.22V output)
Mic: 10kΩ input impedance unbalanced
2mV rms sensitivity (for 1.22V output)
60mV rms max input
Phono: 47kΩ input impedance
1.5mV rms sensitivity @ 1kHz (for 1.22V output)
OUTPUTS: Line: 9V rms max
Headphone: 0.5W into 4747kΩ
Distortion: < 0.01%
SIGNAL-TO-NOISE RATIO: Line: > 96dB
(max output; JIS-A weighted) Mic: > 78dB
Phono: > 87dB
FREQUENCY RESPONSE: Line: 20Hz – 22kHz ±0.5dB
Mic: 20Hz – 20kHz ±0.5dB
Phono: ±1dB (except for controlled attenuation of -3dB
@ 20Hz to reduce rumble and feedback)
GRAPHIC EQUALIZER: ±12dB @ 63Hz
±12dB @ 250Hz
±12dB @ 1kHz
±12dB @ 4kHz
±12dB @ 16kHz
POWER CONSUMPTION: 10W typical
17W w/full headphone output
DIMENSIONS (W x H x D): 19” x 7” x 4” (480mm x 175mm x 95mm)
WEIGHT: 8.7 lbs. (3.2 kg)
MANUAL VERSION 1.0
