4
1 Fuse 11 Clean-water Filler Cap
2 Waste-water Tank 12 Floor-tool Vacuum Hose
3 Clean-water Tank 13 Vacuum Hose
4 Brush Deck 14 Isolator Key
5 Clean-water Filter 15 Floor-tool Lifting Lever
6 Rear Moving Wheels 16 Hour Meter - TTB Machines Only
7 Clean-water On / Off Tap 17 Floor-tool Retaining Knobs
8 Separator 18 Squeegee Blades
9 Clean-water Emptying Hose 19 Deck Locking Mechanism
10 Top Tank (waste-water) Drainage Hose 20 Hose
21 Operator Control Panel
Machine Overview
3
4
5
6
8
10
9
1
7
12
14
15
16
17
11
2
13
18
19
20
17
21
21
